DRILLING PRODUCTS
본문 및 주요 콘텐츠
CONSTRUCTION / SPECIAL RIGS
Popular model : Drilling Rigs
| Model Name |
Main Usage |
Engine Max Power |
Rod Size (mm) |
Max Drilling Deth(m) |
Pull-Up Capacity |
Pull-Down Capacity |
Crowler Type |
Crowler Speed |
Rig Weight |
Rig Size (mm) |
more |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 16HDD | Horizontal Directional Drilling | D4DA 100 HP / 2000 RPM |
8ton | 4ton | Solar 35 | 2.5km/h | 5,500kg | L : 6,000 W : 2,200 H : 1,600 |
→ | ||
| 30HDD | Horizontal Directional Drilling | D6BT 220 HP / 2000 RPM |
30ton | 15ton | Solar 55 | 2.5km/h | 7,500kg | L : 6,000 W : 2,200 H : 1,600 |
→ | ||
| 50HDD | Horizontal Directional Drilling | DL08 260 HP / 1750 RPM |
50ton | 55ton | Solar 75 | 2.5km/h | 7,500kg | L : 9,000 W : 2,200 H : 2,600 |
→ | ||
| 80HDD | Horizontal Directional Drilling | D6CC | 80ton | 80ton | Solar 75V | 2.5km/h | 15,500kg | L : 10,200 W : 2,600 H : 2,400 |
→ | ||
| 120HDD | Horizontal Directional Drilling | D6CC | 120ton | 120ton | 2.5km/h | 16,500kg | → | ||||
| 150HDD | Horizontal Directional Drilling | D6CC | 150ton | 150ton | Solar 130V+S | 2.5km/h | 19,000kg | L : 10,200 W : 2,800 H : 2,400 |
→ |
Popular model : Drilling Rigs
| Model Name |
Main Usage |
Engine Max Power |
Rod Size (mm) |
Max Drilling Deth(m) |
Pull-Up Capacity |
a | b | c | d | e | more |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 100Sonic | Foundation / Tunneling | 100 | → | ||||||||
| 150Sonic | Foundation / Tunneling | 150 | → | ||||||||
| Vibrator | Soft ground drilling | → | |||||||||
| Blast Hole | → |
